750mm & 950mm Cooling Tower Fill with 20mm Vertical Corrugations

This cooling tower fill is available in 750mm and 950mm widths, with a 20mm corrugation pitch and a 90° channel arrangement. The straight corrugated structure provides defined passages for water and airflow, making it suitable for cooling tower applications where consistent channel geometry and reliable installation are important.

Both widths can be supplied with customized lengths and sheet thicknesses. Depending on the tower structure, the fill can be assembled into glued blocks or prepared for hanging installation.

Product Specifications

• Available Widths: 750mm, 950mm
• Length: Customizable
• Thickness: Customizable
• Corrugation Pitch: 20mm
• Corrugation Angle: 90°
• Materials: PVC, CPVC, PP
• Connection Method: Glue or hang

Corrugated Structure and Installation

The 20mm pitch creates relatively open flow passages compared with tighter corrugation designs. The 90° arrangement keeps the channel layout straightforward, which can be useful when matching replacement fill to an existing tower configuration.

For glued assemblies, the sheets can be formed into blocks according to the required packing dimensions. Hanging installation is also available where the tower uses a suitable support arrangement. The installation method should be confirmed against the existing fill support system before production.

Material and Size Options

PVC, CPVC, and PP are available to accommodate different operating conditions. Material selection should take into account circulating water temperature, water chemistry, and the tower's service requirements rather than dimensions alone.

The 750mm and 950mm width options, together with adjustable lengths and thicknesses, allow the fill to be produced for different packing layouts. For replacement projects, existing sheet dimensions and support details can be used to confirm the required configuration.

We support customized production based on tower dimensions, material requirements, and installation arrangements, helping customers obtain fill that fits their equipment without unnecessary modifications to the existing structure.
